stainless still coil

What is SS Coil?

Slabs of stainless steel are produced during the initial production process. These slabs are then converted into coils using a Z mill. The coils are typically made at around 1250 mm wide and are referred to as “mill edge coils.” These networking events are more meticulously processed via a broad range of processing techniques such as slitting, where the wide coil is split into smaller threads. Here you will often see some confusion surrounding the terminology. Stainless steel may be cut according to the slitting process to form perforated coils, which are referred to by many names, including strip coils, slit coils, banding, or just strips.

Tips to find a trustable SS Coil supplier in India

To identify an authentic ss coil supplier in India, you should consider these tips:

  • Look for Stainless Steel Coil providers that have actually been in existence for some time in order to maximize the level of expertise as an outcome. Also, make sure you have looked at their certifications, to confirm that they have met the minimal requirements for the level of quality.
  • Ask for the stock information of SS coil which is applicable to your situation. They ought to have enough stock among their appliances to ensure that you can acquire the pipes you require, without delay.
  • Read about the firm online and read past client testimonials. Try to find out whether the business is transparent in their dealings with clients. Look at their client servicing both online and offline.

Countries We Supply SS Plate To

Steelco Metal & Alloys supply and distribute Stainless Steel products to countries like

US United States

Europe Europe

Middle East Middle East

Africa Africa

and more…

CUTTING

Industrial Application of SS Coils

Stainless Steel Coils are highly versatile and have excellent resistance to heat and corrosion properties. As a result, it can be used across a wide range of industries, such as:

SS Coil Specification

Item SS Coil(Hot rolled, cold rolled)
Inner Diameter
610 +0/-5 mm
Width
610~2000 mm
Thickness
2.5~10.0 mm
Length
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Material
SS 202 Coils, SS 304 Coils, SS 316 Coils, SS 321 Coils, SS 310 Coils , SS 410 Coils, SS 420 Coils, SS 416 Coils
Surface
2D, etching, 8K, 2B, BA, NO.4, hairline,NO.1, NO.8, Brush, checkered, mirror,embossed, sand blast etc
Standard
ASTM A240, ASTM A167, JIS4304-2005, GB/T3280-2007, EN 10088-2-2005, etc
Origin
Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin

SS Coil Sizes

Type Width Thickness Inner Diameter Surface Finish
SS Hot Rolled No.1 Coils
610~2000 mm
2.5~10.0 mm
610 +0/-5 mm
2D, 2B, BA, No.4, No.3,No.5, HL, SB,
SS Cold Rolled Coils
610~1524 mm
0.3~3.0 mm
610 or 508 +0/-5 mm
Pre-painted Stainless Steel Coils
130-1524mm
0.4-3.0mm
-
2B, 2D
Sizes Availability
0.4mm
0.5mm
0.8mm
1mm
1.2mm
1.6mm
2mm
3mm
4mm
5mm
6mm
8mm
10mm
12mm
16mm
20mm
25mm

SS HR Coil Unit Weight Limitation

Unit : ton 5 feet 1M 3 feet 4 feet
300 series
-
-
-
3~22
300 series
3~23 (≦5.0) / 27 (>5.0)
3~18
3~17
3~22

SS CR Coil Dimension and Shape Tolerance

Thickness (mm) 1000 ≤ Width < 1250 (mm) 630 ≤ Width < 1000 (mm) 1250 ≤ Width < 1550 (mm)
0.40 ≤ T < 0.60
±0.035
±0.035
-
1.25 ≤ T < 1.60
±0.060
±0.055
±0.060
1.60 ≤ T < 2.00
±0.070
±0.065
±0.080
0.25 ≤ T < 0.40
±0.035
±0.030
-
0.80 ≤ T < 1.00
±0.050
±0.040
±0.050
0.60 ≤ T < 0.80
±0.040
±0.040
-
1.00 ≤ T < 1.25
±0.055
±0.050
±0.060

SS Coil Useful Information

Chemical Composition

Element 304 316
Carbon
0.07
0.08
Manganese, max
2.00
2.00
Phosphorus, max
0.045
0.045
Sulfur, max
0.030
0.030
Silicon
0.75
0.75
Chromium
17.50 - 19.50
16.00 - 18.00
Nickel
8.00 - 10.50
10.00 - 14.00
Molybdenum
...
2.00 - 3.00
Nitrogen
0.10 max
0.10 max

Mechanical Properties

Type Tensile Strength, ksi, min Yield Strength, ksi, min Elongation, % min Hardness, maxA
304
75
30
40
201 HBW or 92 HRB
316
75
30
40
217 HBW or 95 HRB

Benefits of Stainless Steel Coils

Maintenance

The installation and cleaning of this equipment are quite easy. Just remove them, wash them off, and then put them on. Using these straightforward instructions, you will not have to concern yourself with struggling with wet coils or having dirty hands.

Strength

A stainless steel coil is very strong, tough, and resistant to cold, heat, and erosion. It does not break or crack when exposed to extreme heat and cold.

Energy Conservation

They allow energy to maintain its temperature longer, so less heating and cooling is necessary. Your power bill will be lower as a result.

Competitive Advantage of Steelco Metal & Alloys

Company Services
We enhance our industry operations by relieving you of the worries associated with freight forwarding.

An integrated approach to providing engineering services allows our clients to benefit from the commercial and logistical advantages.

We are one of the Nations largest automotive parts recyclers and a widely recognized leader utilizing advanced computerized techniques.
We’ll work with you on your project, large or small. Together we’ll fine-tune your new construction, remodeling or renovation plans.

FAQ

Stainless steel may be cut according to the slitting process to form perforated coils, which are referred to by many names, including strip coils, slit coils, banding, or just strips.

SS Coil is available in different austenitic grades including CS-B, FS -B, DS-B, DDS, EDDS, A36, SS Grades 30-55, A572-50 HSLA Grades 40-80 and A606. that vary in chemical composition and properties. [know more]

The stainless steel coils find their way into many different industries, such as automotive trim, electronics, medical devices, HVAC ducts, household appliances, springs, and more.

Price of stainless steel coil varies according to the thickness, size and other properties. To know more about price [click here]
